DPP-120Y Small Liquid Blister Packing Machine

作者hanyoo
分享Printerest 分享LinkedIn 分享WhatsApp

This machine is suitable for packing different kind of liquid products such as honey, jam, butter, milk, perfume, red worm. olive oil, etc. The machine adopts programming system control, touch screen panel operation, stepless frequency conversion speed regulation, pneumatic joint control, easy operation and economical.

Play

Properties

ModelDPP-120Y
Cutting Frequency(times/min)10-25
Output capacity(pcs/h)1000-4000
Travel Scope(mm)40-90
Max blister size(mm)120*90*20
Air  consumption(m³/min)≥0.36
Voltage220V50HZ 4.5KW
Plastic film(mm)130*(0.15-0.5)
Aluminum foil(mm)130*(0.02-0.035)
Overall size(mm)1700*460*1070
Weight(kg)530

Production Workflow Chart

Sample Display

Detailed Display

Exhibition

Packaging And Shipping

Why Choose Us

Specialized Factory

Economical Pricing Options

On-Time Delivery

Perfect Customer Service

If you have any questions or need to develop customized equipment solutions, please contact our Email：info@hanyoo.net for the most thoughtful support!

Welcome To Our Blister Packing Machine Line Factory!

Frequently Asked Questions

Why do pharmaceutical products often come in such big packets that are half empty, when the product could easily be packed in a smaller container? Many pharmaceutical products need to be loosely packed to ensure their designated shelf life and to stay intact during transport and storage.

Blister packaging must comply with critical regulatory standards including FDA 21 CFR Part 201, EU GMP Annex 13 and ISO 11607, and CDSCO Schedule M. These standards ensure safety, labeling accuracy, material integrity, and manufacturing compliance essential for pharmaceutical products.

The most common material used in blister packaging is PVC. PVC is formed by thermoforming, which makes the process widely used. For applications requiring better barrier properties, laminated aluminum is the better option, which is formed by cold forming.
